UPDATE RULE PLUGINS

difference


Update rule plugin, augmenting a state with new elements while dropping elements that are common to the state and the new information.

See also: https://creatingintelligence.org/#update-rules

Details

  • Plugin for auto, delay, and temporal components.
  • Transparently handles multisets and inhibitory signals.
  • Corresponds to the set symmetric difference after deduplication.

Auto-associative memory with difference update

As a plugin for the auto component, the difference update rule replaces the memory’s state with the symmetric difference between the query and the retrieved data, removing the matching elements.

This update rule enables generative behavior in auto-associative memory retrieval.

{ "hyperparameters": {"default": [1000, 10]},
  "dataflow": [
    {"component": "input", "send": [1]},
    {"component": "auto", "plugin": "difference",
        "send": [2], "receive": [1]},
    {"component": "output", "receive": [2]}
  ]}


See also: https://creatingintelligence.org/#auto-associative-memory

Temporal associative memory with difference update

Used as a plugin for the temporal component, the difference update rule replaces the internal state with the symmetric multiset difference of the state and the incoming signal.

{ "hyperparameters": {"default": [1000, 10]},
  "dataflow": [
    {"component": "input", "send": [1]},
    {"component": "temporal", "plugin": "difference",
        "send": [11], "receive": [1]},
    {"component": "output", "receive": [11]}
  ]}
