UPDATE RULE PLUGINS

augmentation


Update rule plugin, computing the multiset aggregation of signals.

See also: https://creatingintelligence.org/#update-rules

Details

  • Plugin for auto, delay, and temporal components.
  • Computes the multiset aggregation of its inputs.
  • Corresponds to the set union after deduplication.

Auto-associative memory with augmentation update

As a plugin for the auto component, augmentation aggregates the memory’s state with the retrieved value, then deduplicating the multiset to give its underlying set of unique elements.

The augmentation rule completes the input while retaining non-matching elements. Used iteratively in conjunction with stochastic subsampling, this mechanism converges incrementally to a stable state.

{ "hyperparameters": {"default": [1000, 10]},
  "dataflow": [
    {"component": "input", "send": [1]},
    {"component": "auto", "plugin": "augmentation",
        "send": [2], "receive": [1]},
    {"component": "output", "receive": [2]}
  ]}


See also: https://creatingintelligence.org/#auto-associative-memory

Delay component with temporal state augmentation

The delay component uses the augmentation mechanism for temporal signal integration.

{ "hyperparameters": {"default": [1000, 10]},
  "dataflow": [
    {"component": "input", "send": [1]},
    {"component": "delay", "plugin": "augmentation",
        "send": [11], "receive": [1], "capacity": 2, "decay": 0.15},
    {"component": "output", "receive": [11]}
  ]}


Temporal associative memory with state augmentation

Used as a plugin for the temporal component, augmentation aggregates an orderless state representing prior inputs.

{ "hyperparameters": {"default": [1000, 10]},
  "dataflow": [
    {"component": "input", "send": [1]},
    {"component": "temporal", "plugin": "augmentation",
        "send": [11], "receive": [1], "capacity": 5},
    {"component": "output", "receive": [11]}
  ]}
